| Touch C/B | ICI2511P.C2.P1.V1 | ILI2511P.C2.P2.V1 | ILI2511P.C3.P1.V1 |
| Board Size | L=50mm,W=26mm | L=50mm,W=26mm | L=72mm,W=28mm |
| Channels | RX41*TX23 ; RX32*TX24 | RX41*TX23 ; RX32*TX24 | RX41*TX23 |
| Host Interface | USB+I2C | USB+I2C | USB+I2C+RS232 |
| FPC Connector | 68 pin_0.5 Pitch | 68 pin_0.5 Pitch | 68 pin_0.5 Pitch |
| Noise Immunity | CS :10Vrms | CS :10Vrms | CS :10Vrms |
| T5 Lamp(4-feet) Distance 15cm | T5 Lamp(4-feet) Distance 15cm | T5 Lamp(4-feet) Distance 15cm | |
| GND Gasket | Yes | Yes | Yes |
| Support Size | ≦15.6” | ≦15.6” | ≦15.6” |
| Support Size (Pass Win 8/10) | ≦10.1” | ≦10.1” | ≦10.1” |
| Passive Stylus | 0.6*sensor pitch @ CG <=10mm | 0.6*sensor pitch @ CG <=10mm | 0.6*sensor pitch @ CG <=10mm |
| Support CG | ≦10mm (suggest ≦ 6mm) | ≦10mm (suggest ≦ 6mm) | ≦10mm (suggest ≦ 6mm) |
| Waterproof | 10cc water drop No ghost | 10cc water drop No ghost | 10cc water drop No ghost |
| 1cc water spray 1 touch points | 1cc water spray 1 touch points | 1cc water spray 1 touch points | |
| Glove | ≦ 2mm @ CG ≦ 8mm | ≦ 2mm @ CG ≦ 8mm | ≦ 2mm @ CG ≦ 8mm |
